H683 - HED 6"x8” 3-Way Coaxial Full Range Speaker Set

3-Way Coaxial Design for Full-Range Performance

The H683 features a 6X8” woofer, 2.5” midrange, and 1” PEI tweeter, creating a comprehensive audio spectrum that covers all frequencies with outstanding detail and clarity. The polypropylene cone offers accurate, deep bass and smooth midrange, while the UV-treated foam surround provides durability. The dynamically balanced 1” PEI tweeter, powered by a neodymium magnet, produces bright, crisp highs, completing the full-range sound profile with exceptional clarity.

Features:

• 6X8” Woofer, 2.5” Midrange, & 1” PEI Tweeter – A 3-way coaxial design that covers all frequencies for full-range sound, from deep bass to clear, detailed highs.
• Responsive Polypropylene Cone – Delivers precise, low-end bass and smooth midrange frequencies, offering a balanced and dynamic sound.
• UV-Treated Foam Surround – Ensures durability, providing long-lasting reliability and high-performance sound in any environment.
• Dynamically Balanced 1” PEI Tweeter – Produces bright, distortion-free highs with excellent clarity, adding brilliance to your sound system.
• Integrated Crossover with Tweeter Protection – Ensures smooth frequency transitions while protecting the tweeter from distortion at high volumes.
• Strontium Ferrite Woofer Magnet – Delivers powerful bass and midrange response, adding depth and warmth to your music.
• Powder-Coated, Rigid Stamped Steel Basket – Reduces unwanted vibrations and distortion, ensuring a stable and distortion-free sound.
• Sold in Pairs – Perfect for building or upgrading a high-quality audio system with a full-range, 3-way coaxial speaker solution.

Specifications:

• Power: 45W RMS/140W MAX
• Frequency Response: 87Hz-20KHz
• Sensitivity (1W/1M): 87dB
• Nominal Impedance: 4Ω
• Free Air Resonance (FO): 76Hz
• Overall Diameter: 5.51"x7.60" (110mm x 277mm)
• Cut-Out Diameter: 5"x7.09" (96mm x 239mm)
• Mounting Depth: 2.28" (58mm)
